RAM® Double Socket Arm with Diamond Ball Plate (RAM-103-D-238U)
The RAM-103-D-238U consists of the 1.5" C size diameter ball and socket system with one open socket end; RAM-201U-D socket arm is long length at 9.125" end to end with a 8" socket-to-socket length. This mount is designed to be used with any of the C size RAM® Mount bases or cradles with a 1.5" diameter rubber ball. The RAM-238U RAM® Diamond Ball Base features industry standard AMPS 2-hole pattern and can be used as an adapter to attach a holder or a mounting drill-down base.
Specs & Features
- Diamond plate connects to RAM® device holders containing the universal AMPS 2-hole pattern
- Includes C size long length double socket arm 9.125" end to end with a 8" socket-to-socket length; ball and socket technology allows for near-infinite adjustability
- Made of powder-coated, marine-grade aluminum for durability and reliability in the most demanding environments
- Backed by a lifetime warranty
- Socket-to-Socket Length: 8"
- 2-hole AMPS: 1.912"
- Plate Size: 2.43" x 1.31"
- Ball Size: C Size (1.5")
- Weight Capacity Standard Use: 4 lbs
- Weight Capacity Heavy-Duty Use: 3 lbs
- Materials: Marine-grade aluminum
- Weight: 1.8154 lbs.
